ISCAR MILL-4-FEED FFQ4 12 MILLING FAMILY

ISCAR recently expanded the tool and insert options of the immensely popular FFQ4-12 milling family to include new tools and insert geometries.

The FFQ4-12 tools carry square single-sided inserts with four cutting edges, designed for reducing cutting forces when used on low power machines or long overhang applications.

The FFQ4 D…-12 shell mill cutters feature a coarse-pitch option for 40 and 50 mm cutters and for 52 and 66 mm cutters, which extends the range of application options for roughing operations in the die & mould and aerospace industries and in general engineering.

The FFQ4 inserts are produced from ISCAR’s latest SUMOTEC carbide grades, ensuring high productivity.

Insert types include:

• FFQ4 SOMT 125 single-sided square insert with four cutting edges, featuring five cutting geometries for optimal machining of different materials
• FFQ4 SOMT 12516T for steel, ferritic and martensitic stainless steel, cast iron and hardened steel; FFQ4 SOMT 12516HP for austenitic stainless steel and high temperature alloys
• FFQ4 SOMT 120516T20 for grey and nodular cast iron; FFQ4 SOMT 1205RM-T for interrupted cut and for machining near straight wall shoulders of steel, ferritic and martensitic stainless steel, cast iron and hardened steel
• FFQ4 SOMT 1205RM-HP for interrupted cut and for machining near straight wall shoulders of austenitic stainless steel and high temperature alloys

The FFQ4 D…-12 tool features a 9˚ cutting edge angle, positive axial rake angle, ramping down capability, a 3.1 mm radius for programming, with fine pitch and coarse pitch cutter versions. Internal coolant holes are directed to each cutting edge and the cutter body has a special protective polished coating for uninterrupted chip flow and protection from corrosion and wear.

For more information, please contact ISCAR South Africa (PTY) LTD – Tel: 011 997-2700.

HELI – 3 – MILL – HM390 TRIANGULAR INSERTS NOW WITH 5 MM HELICAL CUTTING EDGES

ISCAR recently expanded its HM390 line of milling tools with triangular insert line with HELI-3-MILL – a family of indexable cutters carrying the HM390 TPKT 0502PDR 5 mm edge triangular insert. The design, based on its successful predecessors, provides a smaller insert, enables high metal removal rates, and offers an effective and economical solution for milling 90º shoulders.

The HELI-3-MILL tools are intended for applications that are traditionally aimed for solid carbide endmills. Designed for productive rough milling at high feed rates of compact parts, small-size cavities, pockets, etc., the new tools are particularly applicable to miniature parts manufacturing, medical components and more. While they offer an ideal solution for low power machining centers and turn-milling machine tools, the low power consumption allows the cutters to be applied on machine tools with limited power, small capacity machining centers and turn-milling machines.

Available in a 10 – 16 mm diameter range, the tools feature a 90º cutting edge angle, advanced cutting geometry to reduce cutting forces and provides smooth cutting, ramping down ability and a maximum 3.5 mm depth of cut. Coolant holes are directed to each cutting edge and the cutter body  has a special protective polished coating for uninterrupted chip flow and protection from corrosion and wear.

Reduced feed per tooth working values contribute to decreasing impact load and ensure soft and light cutting action, while the high tooth density, enabled by the small-size insert facilitates stable cutting due to several teeth engaging in the material during milling.

The HM390 TPKT 0502PDR single-sided triangular inserts feature three helical cutting edges, with progressive cutting geometry providing positive radial and axial rake angles on the cutter, and a wiper flat for improved surface finish. The inserts are produced from ISCAR’s latest SUMO TEC carbide grades, which significantly increase productivity.

The HM390 TPCT 0502PDR peripherally ground inserts integrate a sharp cutting edge used for semi-finishing and finishing applications. The insert enables smooth machining, exerting low cutting forces, and is specially designed for milling various high-temperature alloys. These features allow a higher table feed to be applied in shallow milling applications.

The following HELI-3-MILL cutter types are available at this stage: HM390 ETP…-05 endmills carrying the triangular HM390 TPKT 0502PDR inserts in a diameter range of 10 – 16 mm, and HM390 ETP…MM-05 endmills with MULTI-MASTER threaded adaptation in 10, 12, 14 and 16 mm diameters, carrying HM390 TPKT 0502PDR triangular inserts. The MULTI-MASTER connection expands the variety of tool configurations.

Shank types are available in cylindrical and conical shanks in a wide selection of diameters, lengths and materials, allowing operators to choose the proper shank according to their application requirements. Indexing is fast and convenient due to the threaded connection. Since the tool is not removed from the machine, no set-up time is required for tool head replacement.

The HELI-3-MILL family offers a productive solution in a broad spectrum of milling applications, including rough to finish machining on main engineering materials and milling square shoulders, planes (especially next to shoulders), slots, and inclined surfaces and cavities by ramping or helical interpolation. The unique tool design significantly minimizes and even eliminates mismatch in multi-pass milling of high shoulders.

For more information, please contact ISCAR South Africa (PTY) LTD – Tel: 011 997-2700.
